• KIP 890
  • KIP 890
1 2

KIP

KIP 890

KIP 890

$49,683.00 USD
$49,683.00 USD
Sale Sold out

The KIP 890 delivers unmatched multi-function copy, scan and print performance for high demand enterprise workflow. Engineered to deliver vibrant, consistent color quality from first to final print. The integrated dual footprint configuration multitasks scan and print production, saving valuable project time.

  • 4 Roll Multi-Function System with Integrated Scanner
  • KIP 890 includes a KIP 2300 CCD Scanner
  • 12” Smart System K Touchscreen
  • Standard Front Stacking
  • Optional Rear Stacking or KIPFold

        View full details

        Product Specifications

        KIP 890

        Product Description

        The KIP 890 delivers unmatched multi-function copy, scan and print performance for high demand enterprise workflow. Engineered to deliver vibrant consistent color quality from first to final print. The integrated dual footprint configuration multitasks scan and print production, saving valuable project time.

        General

        DESCRIPTION
        4 Roll Color Production System with KIP 2300 CCD Scanner

        TYPE
        LED Array Electro photography with organic photoconductor (OPC drum) Contact Development using non magnetic mono-component toner

        CONFIGURATIONS
        Multi-function system (print/copy/scan)

        SPEED
        Up to 3,600 sq. ft (334 m2) in single pass black or 2,880 sq. ft. (268 m2) per hour in color regardless of image type or print resolution

        WARM UP TIME
        Instant from standby, less than 6 minutes from power on

        TONER
        Four color (CMYK), dry toner, print images are UV resistant and waterproof

        INPUT TOWER
        208-240VAC +6%/-10% 50/60Hz, 16 A

        POWER CONSUMPTION
        Ready: 0.6 kWh
        Printing: 1.9 kWh
        Warm Up: 3.4 kWh
        Sleep Mode: 3 Wh

        ACOUSTIC NOISE
        < 65 db Printing

        OZONE
        < 0.05 ppm (average of 8 hours)

        DIMENSION
        78” x 43” x 48"

        WEIGHT
        1,225 lbs

        Printer

        PRINT RESOLUTION
        600 x 2,400 dpi

        PAPER CAPACITY
        3,000 sq ft / 280 sq m ( 2 rolls + cut sheet )
        6,000 sq ft / 560 sq m ( 4 rolls + cut sheet )

        OUTPUT SIZES WIDTH (roll media)
        11” - 36” / 297 mm - 914 mm (3” Core)

        OUTPUT SIZES LENGTH (roll media)
        8.5” / 210 mm minimum, 210’ / 64 m maximum

        PAPER WEIGHT (roll media)
        Bond: 18 – 40 lb / 67 – 150 gsm,
        Film: 3 – 4 mil Double Matte Polyester
        Tracing: 18 – 20 lb / 67 – 75 gsm

        SHEET BYPASS
        Up to 40 lbs. / 150 gsm bond
        Maximum sheet size 36”/ 914 mm x manageable length
        Minimum sheet size 11” x 17” / A3

        MEDIA TYPES
        Bond Paper: Economical Bond, Standard Bond
        Specialty Bond paper: Presentation Bond, Heavy Weight Bond
        Polyester Film: 3 mil Clear, 3 mil Double Matte, 4 mil White Opaque
        Banner Media: Fusion Soft Polyester

        Controller

        CONTROLLER TYPE
        System K Embedded, Windows Standard Embedded 7 – 64 bit, i5 Quad Cord (min)

        MEMORY
        4 GB (min)

        SOLID STATE DRIVE
        320 GB minimum unlimited upgrade

        COMPATIBLE FILE FORMATS
        Raster Color: TIFF, JPG, JPG2000, PNG,
        BMP, GIF, TGA, RLE/RLC
        Vector Color/B&W: HPGL, HPGL/2, HP-RTL,
        Postscript (PS/EPS), Adobe PDF, Autodesk DWF,
        Multipage PDF & DWF
        Raster B&W: TIFF Group 3 & 4, CALS Group 4,
        Grayscale TIFF
        Vector B&W: Calcomp 906/907

        Scanner

        SCAN RESOLUTION
        600 dpi (optical)

        ORIGINAL
        Single Sheet, image viewable/face up

        WIDTH
        8.5” - 36” / 210 mm - 914 mm

        LENGTH
        8.5” – 19.7’ / 210 mm – 6 m
